Technical specifications:
- Power supply 12V 30A max (with reverse polarity protection).
- Five 12V outputs for high power 5.5x2.1 cylindrical connector. Each output can deliver up to 5A and is protected against overcurrent and short circuit with an electronic fuse that resets itself in about 10 seconds.
- USB2 hub 7 ports high speed (480 Mbit) self powered. The maximum current that can be supplied is 6A distributed among all the ports. Each port is protected against electrostatic discharges, short circuits and overcurrent greater than 2A.
- a power USB port (useful for powering anti-condensation bands / led panels / raspberry / asiair etc.). It supplies power (without data exchange) to any external device. It is protected against overcurrent and short circuit with an electronic fuse.
